1808926

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 13 POS 5.08MM PITCH PLUG 20-14 AWG CRIMP

Search across all available documentation for this part.

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 13 POS 5.08MM PITCH PLUG 20-14 AWG CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	1808926

Color	Green
Current - IEC	12 A
Current - UL	10 A
Housing Material	Polyamide (PA), Nylon
Insulation Height	10 mm
Insulation Height	0.394 "
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	13
Pitch [x]	0.2 in
Pitch [x]	5.08 mm
Positions Per Level	13
Type	Plug Housing for Female Sockets
Voltage - IEC	630 V
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	20 AWG
Wire Gauge or Range - AWG [Min]	14 AWG
Wire Gauge or Range - mm˛ [Max]	2.5 mm˛
Wire Gauge or Range - mm˛ [Min]	0.2 mm˛

Pluggable Terminal Blocks 13 Pos 5.08mm pitch Plug 20-14 AWG Crimp

Part	Material Flammability Rating	Mounting Type	Voltage - IEC	Current - UL	Color	Number of Positions	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Number of Levels	Pitch [x]	Pitch [x]	Current - IEC	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Type	Positions Per Level	Voltage - UL	Housing Material	Insulation Height	Insulation Height
Phoenix Contact 1808926	UL94 V-0	Free Hanging (In-Line)	630 V	10 A	Green	13	20 AWG	14 AWG	1	0.2 in	5.08 mm	12 A	0.2 mm˛	2.5 mm˛	Plug Housing for Female Sockets	13	300 V	Polyamide (PA) Nylon	10 mm	0.394 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pluggable Terminal Blocks 13 Pos 5.08mm pitch Plug 20-14 AWG Crimp
