AA04D1515A
ActiveDelta Electronics
AC/DC POWER SUPPLY DUAL-OUT -15V/15V -0.133A/0.133A 4W 7-PIN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AA04D1515A
ActiveDelta Electronics
AC/DC POWER SUPPLY DUAL-OUT -15V/15V -0.133A/0.133A 4W 7-PIN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AA04D1515A |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | UL, CE |
| Current - Output (Max) | 133 mA |
| Current - Output (Max) | 133 mA |
| Efficiency | 77 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 0.5 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 7-DIP Module |
| Power (Watts) | 4 W |
| Size / Dimension [x] | 1.44 " |
| Size / Dimension [x] | 36.5 mm |
| Size / Dimension [y] | 1.06 in |
| Size / Dimension [y] | 27 mm |
| Size / Dimension [z] | 0.67 in |
| Size / Dimension [z] | 17.1 mm |
| Standard Number | 60950-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 370 VDC, 264 VAC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Output 1 | 15 V |
| Weight | 0.057 lb |
| Weight | 25.85 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 23.91 | |
| 5 | $ 22.16 | |||
| 10 | $ 21.00 | |||
| 25 | $ 19.83 | |||
| 50 | $ 17.50 | |||
| 100 | $ 16.33 | |||
| 250 | $ 16.04 | |||
| 500 | $ 15.75 | |||
Description
General part information
AA04D Series
Enclosed AC DC Converters 2 Output 15V 133mA, 133mA 85 ~ 264 VAC, 120 ~ 370 VDC Input
