RID-125-1224
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 12V 24V 133W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
RID-125-1224
ActiveMEAN WELL USA Inc.
AC/DC CONVERTER 12V 24V 133W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RID-125-1224 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, CE, cURus, TUV |
| Current - Output 1 | 3.7 A |
| Current - Output 2 | 3.7 A |
| Efficiency | 85 % |
| Features | Adjustable Output |
| Minimum Load Required | True |
| Mounting Type | Chassis Mount |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Power (Watts) | 133 W |
| Size / Dimension [x] | 199 mm |
| Size / Dimension [x] | 7.83 in |
| Size / Dimension [y] | 3.86 in |
| Size / Dimension [y] | 98 mm |
| Size / Dimension [z] | 1.5 " |
| Size / Dimension [z] | 38 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 373 VDC, 132 VAC |
| Voltage - Input [Min] | 248 VDC, 88 VAC, 176 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 12 V |
| Voltage - Output 2 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 42.04 | |
| 5 | $ 39.61 | |||
| 10 | $ 38.60 | |||
| 25 | $ 37.31 | |||
Description
General part information
RID-125 Series
Enclosed AC DC Converters 2 Output 12V 24V 88 ~ 132 VAC, 176 ~ 264 VAC, 248 ~ 373 VDC Input
