1328A 0061000

Active

Belden Inc.

MULTI-PAIR 10CON 18AWG BLU

Search across all available documentation for this part.

Active

Belden Inc.

MULTI-PAIR 10CON 18AWG BLU

Technical Specifications

Parameters and characteristics for this part

Specification	1328A 0061000

Cable Type	Multi-Pair
Conductor Insulation	Polyolefin (PO)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Features	Rip Cord, Drain Wire
Jacket (Insulation) Diameter [diameter]	13.97 mm
Jacket (Insulation) Diameter [diameter]	0.55 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Blue
Length	1000 ft
Length	304.8 m
Number of Conductors	10
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Voltage	300 V
Wire Gauge	18 AWG

Part	Length	Length	Jacket (Insulation) Material	Jacket Color	Shield Material	Conductor Insulation	Wire Gauge	Conductor Material	Operating Temperature [Min]	Operating Temperature [Max]	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Voltage	Conductor Strand [custom]	Conductor Strand [custom]	Shield Type	Cable Type	Shield Coverage
Belden Inc. 1328A 0061000	1000 ft	304.8 m	Poly-Vinyl Chloride (PVC)	Blue	Aluminum	Polyolefin (PO)	18 AWG	Copper Tinned	-40 °C	105 ░C	Drain Wire Rip Cord	13.97 mm	0.55 in	10	300 V	26 AWG	7	Foil	Multi-Pair	100 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 6.86

General part information

10 (5 Pair) Conductor Multi-Pair Cable Blue 18 AWG Foil 1000.0' (304.8m)
