C146 10A006 000 1

Active

Amphenol Tuchel Industrial

INSERT MALE 6POS+1GND CRIMP

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

INSERT MALE 6POS+1GND CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	C146 10A006 000 1

Color	Gray
Connector Type	Insert without Contacts
Contact Type	C 16-3
Current Rating (Amps)	10 A
Gender	Male
Material Flammability Rating	UL94 V-0
Number of Positions	6+Ground
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Termination Style	Crimp
Voltage Rating	600 V

Part	Material Flammability Rating	Voltage Rating	Gender	Termination Style	Connector Type	Contact Type	Current Rating (Amps)	Number of Positions	Color	Operating Temperature [Max]	Operating Temperature [Min]
Amphenol Tuchel Industrial C146 10A006 000 1	UL94 V-0	600 V	Male	Crimp	Insert without Contacts	C 16-3	10 A	6+Ground	Gray	125 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 10.59

General part information

Male Insert without Contacts Gray 6+Ground Position Crimp
