MOVHE14V230Y
ActiveEaton - Electronics Division
VARISTOR 230 VAC HE 14MM DISC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MOVHE14V230Y
ActiveEaton - Electronics Division
VARISTOR 230 VAC HE 14MM DISC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MOVHE14V230Y |
|---|---|
| Capacitance @ Frequency | 560 pF |
| Current - Surge | 6 kA |
| Maximum AC Volts [Max] | 230 V |
| Maximum DC Volts [Max] | 300 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 14 mm |
| Package / Case | Disc |
| Varistor Voltage (Max) [Max] | 396 V |
| Varistor Voltage (Min) [Min] | 324 V |
| Varistor Voltage (Typ) | 360 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 0.93 | |
| 10 | $ 0.58 | |||
| 25 | $ 0.48 | |||
| 100 | $ 0.38 | |||
| 250 | $ 0.32 | |||
| 500 | $ 0.29 | |||
| 1000 | $ 0.26 | |||
| 2500 | $ 0.23 | |||
| 5000 | $ 0.22 | |||
Description
General part information
MOVHE14 Series
360 V 6 kA Varistor 1 Circuit Through Hole Disc 14mm
Documents
Technical documentation and resources
