5962-8876903FC

Active

Broadcom Limited

OPTOISO 1.5KV PUSH PULL 16FLATPK

Search across all available documentation for this part.

Active

Broadcom Limited

OPTOISO 1.5KV PUSH PULL 16FLATPK

Technical Specifications

Parameters and characteristics for this part

Specification	5962-8876903FC

Common Mode Transient Immunity (Min) [Min]	1 kV/µs
Current - DC Forward (If) (Max) [Max]	8 mA
Current - Output / Channel	15 mA
Data Rate	5 MBd
Input Type	DC
Inputs - Side 1/Side 2	4/0
Mounting Type	Surface Mount
Number of Channels	4
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Output Type	Totem Pole, Push-Pull
Package / Case	16-FlatPack
Propagation Delay tpLH / tpHL (Max)	350 ns, 350 ns
Rise / Fall Time (Typ) [custom]	45 ns
Rise / Fall Time (Typ) [custom]	10 ns
Supplier Device Package	16-Flatpack
Voltage - Forward (Vf) (Typ)	1.3 V
Voltage - Isolation	1.5 kV
Voltage - Supply [Max]	20 V
Voltage - Supply [Min]	4.5 V

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Current - DC Forward (If) (Max) [Max]	Propagation Delay tpLH / tpHL (Max)	Mounting Type	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Current - Output / Channel	Voltage - Isolation	Package / Case	Number of Channels	Common Mode Transient Immunity (Min) [Min]	Inputs - Side 1/Side 2	Input Type	Operating Temperature [Min]	Operating Temperature [Max]	Data Rate	Output Type	Voltage - Forward (Vf) (Typ)	Supplier Device Package
Broadcom Limited 5962-8876903FC	20 V	4.5 V	8 mA	350 ns 350 ns	Surface Mount	45 ns	10 ns	15 mA	1.5 kV	16-FlatPack	4	1 kV/µs	4/0	DC	-55 °C	125 °C	5 MBd	Push-Pull Totem Pole	1.3 V	16-Flatpack

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Logic Output Optoisolator 5MBd Push-Pull, Totem Pole 1500VDC 4 Channel 1kV/µs CMTI 16-FlatPack
