7084-1

Active

BRADY

B946 7084-1 WHT/GRN STY-1

Search across all available documentation for this part.

Active

BRADY

B946 7084-1 WHT/GRN STY-1

Technical Specifications

Parameters and characteristics for this part

Specification	7084-1

Application Specifics	Water Fluids
Applications	Pipe
Arrangement	Text Only
Color - Background	Green
Color - Legend	White
Features	Oil Resistant, Chemical Resistant, Water Resistant
Language	English
Legend (Symbol Only)	False
Legend (Text)	Domestic Cold Water
Length	14 in
Length	355.6 mm
Location	Outdoor
Material - Body	Vinyl
Mounting Type	Adhesive
Outside Pipe Diameter (Max) [diameter]	2.5 "
Outside Pipe Diameter (Max) [diameter]	63.5 mm
Outside Pipe Diameter (Min) [Min] [diameter]	200.03 mm
Outside Pipe Diameter (Min) [Min] [diameter]	7.875 in
Print Type	Pre-Printed
Shape	Rectangle
Width	2 1/4"
Width	2.25 in
Width	57.15 mm

Part	Legend (Symbol Only)	Applications	Legend (Text)	Arrangement	Color - Legend	Location	Length	Length	Language	Color - Background	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Shape	Material - Body	Mounting Type	Application Specifics	Width [x]	Width [x]	Features	Print Type	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Width	Width	Width	Outside Pipe Diameter (Max) [diameter]	Outside Pipe Diameter (Max) [diameter]
BRADY 7084-4		Pipe	Domestic Cold Water	Text Only	White	Outdoor	177.8 mm	7 in	English	Green	2.375 in	60.33 mm	Rectangle	Vinyl	Adhesive	Water Fluids	1.125 in	28.58 mm	Chemical Resistant Oil Resistant Water Resistant	Pre-Printed	19.05 mm	3/4	0.75 "
BRADY 7084-1		Pipe	Domestic Cold Water	Text Only	White	Outdoor	355.6 mm	14 in	English	Green	7.875 in	200.03 mm	Rectangle	Vinyl	Adhesive	Water Fluids			Chemical Resistant Oil Resistant Water Resistant	Pre-Printed				2 1/4"	2.25 in	57.15 mm	2.5 "	63.5 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 4.37
