SMC392LB G/W
ActiveAmerican Opto Plus LED
DISP 14SEG 0.39 DUAL BLUE 10DIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SMC392LB G/W
ActiveAmerican Opto Plus LED
DISP 14SEG 0.39 DUAL BLUE 10DIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SMC392LB G/W |
|---|---|
| Color | Blue |
| Common Pin | Common Cathode |
| Current - Test | 20 mA |
| Digit/Alpha Size | 0.39 in |
| Digit/Alpha Size | 10 mm |
| Display Type | 7-Segment |
| Millicandela Rating | 40 mcd |
| Number of Characters | 2 |
| Package / Case | 10-DIP |
| Power Dissipation (Max) [Max] | 120 mW |
| Size / Dimension [x] | 15 mm |
| Size / Dimension [x] | 0.591 in |
| Size / Dimension [y] | 0.772 " |
| Size / Dimension [y] | 19.6 mm |
| Size / Dimension [z] | 0.15 " |
| Size / Dimension [z] | 3.8 mm |
| Voltage - Forward (Vf) (Typ) | 3.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 4.78 | |
| 10 | $ 3.59 | |||
| 100 | $ 2.99 | |||
| 500 | $ 2.09 | |||
| 750 | $ 1.91 | |||
Description
General part information
SMC392 Series
Display Modules - LED Character and Numeric Blue 7-Segment 2 Character Common Cathode 3.2V 20mA 0.591" H x 0.772" W x 0.150" D (15.00mm x 19.60mm x 3.80mm) 10-DIP
