MCC750-1T24
ActiveEOS Power India Private Ltd
AC/DC CONVERTER 24V 756W
Deep-Dive with AI
Search across all available documentation for this part.
MCC750-1T24
ActiveEOS Power India Private Ltd
AC/DC CONVERTER 24V 756W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MCC750-1T24 |
|---|---|
| Applications | Medical |
| Approval Agency | cURus, DEMKO, CE |
| Current - Output 1 | 31.5 A |
| Efficiency | 94 % |
| Features | Universal Input, Remote Sense, Remote On/Off, Adjustable Output, PFC |
| Minimum Load Required | False |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Power (Watts) | 756 W |
| Size / Dimension [x] | 234 mm |
| Size / Dimension [x] | 9.21 in |
| Size / Dimension [y] | 4 " |
| Size / Dimension [y] | 101.6 mm |
| Size / Dimension [z] | 41 mm |
| Size / Dimension [z] | 1.61 " |
| Standard Number | 60601-1 |
| Type | Open Frame |
| Voltage - Input [Max] | 305 VAC, 300 VDC |
| Voltage - Input [Min] | 120 VDC, 85 VAC |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 727.96 | |
| 5 | $ 704.48 | |||
| 10 | $ 680.99 | |||
Description
General part information
MCC750 Series
Open Frame AC DC Converters 1 Output 24V 85 ~ 305 VAC, 120 ~ 300 VDC Input
