LQA30B200C

Active

Power Integrations

DIODE ARRAY GP 200V 15A TO220AB

Search across all available documentation for this part.

Active

Power Integrations

DIODE ARRAY GP 200V 15A TO220AB

Technical Specifications

Parameters and characteristics for this part

Specification	LQA30B200C

Current - Average Rectified (Io) (per Diode)	15 A
Current - Reverse Leakage @ Vr	500 µA
Diode Configuration	1 Pair Common Cathode
Mounting Type	Through Hole
Operating Temperature - Junction [Max]	150 °C
Operating Temperature - Junction [Min]	-55 °C
Package / Case	TO-220-3
Reverse Recovery Time (trr)	16.5 ns
Speed	200 mA, 500 ns
Supplier Device Package	TO-220AB
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	200 V
Voltage - Forward (Vf) (Max) @ If	1.2 V

Part	Mounting Type	Voltage - Forward (Vf) (Max) @ If	Diode Configuration	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Technology	Voltage - DC Reverse (Vr) (Max) [Max]	Supplier Device Package	Speed	Package / Case	Current - Average Rectified (Io) (per Diode)	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Operating Temperature - Junction	Current - Average Rectified (Io)
Power Integrations LQA30T200C	Through Hole	1.2 V	1 Pair Common Cathode	16.5 ns	500 µA	Standard	200 V	TO-220AB	200 mA 500 ns	TO-220-3	15 A	150 °C	-55 °C
Power Integrations LQA30T150C	Through Hole	1.2 V	1 Pair Common Cathode	16.3 ns	500 µA	Standard		TO-220AB	200 mA 500 ns	TO-220-3	15 A	150 °C	-55 °C
Power Integrations LQA30T300	Through Hole	1.95 V		13.7 ns	250 µA	Standard	300 V	TO-220AC	200 mA 500 ns	TO-220-2				150 °C	30 A
Power Integrations LQA30B200C	Through Hole	1.2 V	1 Pair Common Cathode	16.5 ns	500 µA	Standard	200 V	TO-220AB	200 mA 500 ns	TO-220-3	15 A	150 °C	-55 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode Array 1 Pair Common Cathode 200 V 15A Through Hole TO-220-3
