EL100D20-05N

Active

Sensata-Crydom

SSR RELAY SPST-NO 20A 3-100V

Search across all available documentation for this part.

Active

Sensata-Crydom

SSR RELAY SPST-NO 20A 3-100V

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Voltage - Load [Min]	Voltage - Load [Max]	Supplier Device Package	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Voltage - Input [Min]	Voltage - Input [Max]	On-State Resistance (Max) [Max]	Termination Style	Approval Agency	Load Current	Package / Case
Sensata-Crydom EL100D20-12	Chassis Mount	3 V	100 V	Module	-30 ░C	80 C	DC	10 V	14 V	13 mOhms	Quick Connect - 0.250" (6.3mm)	CE cURus TUV	20 A	Module
Sensata-Crydom EL100D20-05	Chassis Mount	3 V	100 V	Module	-30 ░C	80 C	DC	4 V	8 VDC	13 mOhms	Quick Connect - 0.250" (6.3mm)	CE cURus TUV	20 A	Module
Sensata-Crydom EL100D20-24N	Chassis Mount	3 V	100 V	Module	-30 ░C	80 C	DC	21 V	27 V	13 mOhms	Quick Connect - 0.250" (6.3mm)	CE cURus TUV	20 A	Module
Sensata-Crydom EL100D20-24	Chassis Mount	3 V	100 V	Module	-30 ░C	80 C	DC	21 V	27 V	13 mOhms	Quick Connect - 0.250" (6.3mm)	CE cURus TUV	20 A	Module
Sensata-Crydom EL100D20-05N	Chassis Mount	3 V	100 V	Module	-30 ░C	80 C	DC	4 V	8 VDC	13 mOhms	Quick Connect - 0.250" (6.3mm)	CE cURus TUV	20 A	Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 56.06

General part information

Solid State SPST-NO (1 Form A) Module

Technical documentation and resources

No documents available
