TG-A6050-20-10-1.0

Obsolete

t-Global Technology

THERM PAD 20MMX10MM RED

Search across all available documentation for this part.

Obsolete

t-Global Technology

THERM PAD 20MMX10MM RED

Technical Specifications

Parameters and characteristics for this part

Part	Shelf Life	Thickness	Thickness [custom]	Outline [x]	Outline [y]	Thermal Conductivity	Adhesive	Type	Shape	Color	Thickness
t-Global Technology TG-A6050-320-320-0.8	24 Months	0.813 mm	0.032 in	320 mm	320 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red
t-Global Technology TG-A6050-20-10-1.0	24 Months	1 mm		20 mm	10 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Rectangular	Red	0.0394 in
t-Global Technology TG-A6050-10-10-1.0	24 Months	1 mm		10 mm	10 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.0394 in
t-Global Technology TG-A6050-150-150-1.0	24 Months	1 mm		150 mm	150 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.0394 in
t-Global Technology TG-A6050-25-25-1.0	24 Months	1 mm		25 mm	25 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.0394 in
t-Global Technology TG-A6050-25-20-5.0	24 Months	5 mm		25 mm	20 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Rectangular	Red	0.197 "
t-Global Technology TG-A6050-25-25-2.0	24 Months	2 mm		25 mm	25 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.079 in
t-Global Technology TG-A6050-150-150-5.0	24 Months	5 mm		150 mm	150 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.197 "
t-Global Technology TG-A6050-19.5-12.7-2.0	24 Months	2 mm		19.5 mm	12.7 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Rectangular	Red	0.079 in
t-Global Technology TG-A6050-10-10-0.5	24 Months	0.5 mm		10 mm	10 mm	6 W/m-K	Tacky - Both Sides	Conductive Pad Sheet	Square	Red	0.0197 in
