GRF4.0412.013.C

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C14 PANEL QC

Search across all available documentation for this part.

Active

SCHURTER Inc.

PWR ENT RCPT IEC320-C14 PANEL QC

Technical Specifications

Parameters and characteristics for this part

Specification	GRF4.0412.013.C

Accomodates a Fuse	False
Approval Agency	UL, VDE, CSA
Connector Style	IEC 320-C14
Connector Type	Male Blades, Receptacle
Current Rating - Appliance Inlet	10 A
Current Rating - Filter	1 A
Features	Shielded
Filter Type	Filtered (EMI, RFI) - Commercial
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Snap-In
Panel Cutout Dimensions [x]	30.5 mm
Panel Cutout Dimensions [y]	20.8 mm
Panel Thickness [custom]	0.059 in
Panel Thickness [custom]	1.5 mm
Termination	0.189 ", 4.8 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	250 VAC

Part	Approval Agency	Mounting Type	Termination	Termination	Current Rating - Filter	Filter Type	Panel Thickness [custom]	Panel Thickness [custom]	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Connector Style	Features	Ingress Protection	Material Flammability Rating	Accomodates a Fuse	Voltage Rating - Appliance Inlet	Current Rating - Appliance Inlet	Connector Type
SCHURTER Inc. GRF4.0412.013.C	CSA UL VDE	Panel Mount Snap-In	0.189 " 4.8 mm	Quick Connect	1 A	Filtered (EMI RFI) - Commercial	0.059 in	1.5 mm	30.5 mm	20.8 mm	IEC 320-C14	Shielded	IP40	UL94 V-0		250 VAC	10 A	Male Blades Receptacle

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	40	$ 17.12

General part information

Power Entry Connector Receptacle, Male Blades IEC 320-C14 Panel Mount, Snap-In
