THL 25-1210

Active

Traco Power

DC DC CONVERTER 3.3V 20W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER 3.3V 20W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Isolation	Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Input (Max) [Max]	Applications	Voltage - Output 1	Efficiency	Voltage - Input (Min) [Min]	Features	Current - Output (Max) [Max]	Package / Case	Power (Watts)	Number of Outputs	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Mounting Type	Voltage - Output 2
Traco Power THL 25-4813	1.5 kV	Isolated Module	-40 °C	80 ¯C	75 V	ITE (Commercial)	15 V	90 %	36 V	OVP Remote On/Off SCP	1.67 A	6-DIP Module	25 W	1	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole
Traco Power THL 25-2423WI	1.5 kV	Isolated Module	-40 °C	80 ¯C	36 V	ITE (Commercial)	15 V	89 %	9 V	OVP Remote On/Off SCP	840 mA	6-DIP Module	25 W	2	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole	-15 V
Traco Power THL 25-4811	1.5 kV	Isolated Module	-40 °C	80 ¯C	75 V	ITE (Commercial)	5 V	90 %	36 V	OVP Remote On/Off SCP	5 A	6-DIP Module	25 W	1	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole
Traco Power THL 25-1212	1.5 kV	Isolated Module	-40 °C	80 ¯C	18 V	ITE (Commercial)	12 V	89 %	9 V	OVP Remote On/Off SCP	2.09 A	6-DIP Module	25 W	1	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole
Traco Power THL 25-2410	1.5 kV	Isolated Module	-40 °C	80 ¯C	36 V	ITE (Commercial)	3.3 V	88 %	18 V	OVP Remote On/Off SCP	6 A	6-DIP Module	20 W	1	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole
Traco Power THL 25-1210	1.5 kV	Isolated Module	-40 °C	80 ¯C	18 V	ITE (Commercial)	3.3 V	87 %	9 V	OVP Remote On/Off SCP	6 A	6-DIP Module	20 W	1	0.4 "	25.4 mm	1 in	25.4 mm	25.4 mm	10.2 mm	Through Hole
