6ES76470BA000YA2

Active

Siemens

SIMATIC IOT2050

Search across all available documentation for this part.

Active

Siemens

SIMATIC IOT2050

Technical Specifications

Parameters and characteristics for this part

Specification	6ES76470BA000YA2

Approval Agency	UL, RCM, FCC, CE, EAC, cULus, KC
For Use With/Related Products	SIMATIC IOT2050
Mounting Type	DIN Rail
Number of Outputs and Type [custom]	Digital
Number of Outputs and Type [custom]	20
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Termination Style	RJ45
Type	Input, Output (I/O) Module
Voltage - Supply	24 VDC, 12 VDC

Part	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Termination Style	Type	Voltage - Supply	For Use With/Related Products	Storage	Storage	Operating System	Core Processor	Display Type	Memory	Memory	Number of Outputs and Type [custom]	Number of Outputs and Type [custom]
Siemens 6ES76470BA001YA2	CE cULus EAC FCC KC RCM UL	-20 C	70 °C	DIN Rail	RJ45	Interface Module	12 VDC 24 VDC	SIMATIC IOT2050
Siemens 6ES76470BB001YA2
Siemens 6ES76470JB000YA2	CE CSA cULus EAC KC RCM UL	0 °C	45 °C	DIN Rail Wall Mount		Box PC	24 VDC		16 GB	eMMC	Without Operating System	NVIDIA Carmel ARM® Cortex™-V8.2 1.5GHz	No Display	8 GB	LPDDR4
Siemens 6ES76470BA200SP2				DIN Rail	Screw Terminal	Input Output (I/O) Module		SIMATIC IOT2050
Siemens 6ES76470BA000YA2	CE cULus EAC FCC KC RCM UL	-20 C	70 °C	DIN Rail	RJ45	Input Output (I/O) Module	12 VDC 24 VDC	SIMATIC IOT2050								Digital	20

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 484.86

General part information

Input, Output (I/O) Module DIN Rail 12VDC, 24VDC
