3404.0003.24

Active

SCHURTER Inc.

FUSE BRD MNT 63MA 125VAC/VDC SMD

Search across all available documentation for this part.

Active

SCHURTER Inc.

FUSE BRD MNT 63MA 125VAC/VDC SMD

Technical Specifications

Parameters and characteristics for this part

Specification	3404.0003.24

Breaking Capacity @ Rated Voltage	100 A
Current Rating (Amps)	63 mA
Fuse Type	Board Mount
Melting I²t	0.00011
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	2-SMD, J-Lead
Response Time	Fast Blow
Size / Dimension [x]	7.4 mm
Size / Dimension [x]	0.291 "
Size / Dimension [y]	0.122 in
Size / Dimension [y]	3.1 mm
Size / Dimension [z]	2.6 mm
Size / Dimension [z]	0.102 "
Voltage Rating - AC	125 V
Voltage Rating - DC	125 VDC

Part	Voltage Rating - DC	Breaking Capacity @ Rated Voltage	Fuse Type	Voltage Rating - AC	Melting I²t	Response Time	Mounting Type	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]
SCHURTER Inc. 3404.0003.24	125 VDC	100 A	Board Mount	125 V	0.00011	Fast Blow	Surface Mount	63 mA	-55 °C	125 °C	2-SMD J-Lead	0.122 in	7.4 mm	2.6 mm	3.1 mm	0.291 "	0.102 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 1.68
	Digi-Reel®	1	$ 1.68
	Tape & Reel (TR)	3000	$ 0.66

General part information

63 mA 125 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
