VX78012-1000

CUI Inc.

DC DC CONVERTER 12V 12W

Search across all available documentation for this part.

CUI Inc.

DC DC CONVERTER 12V 12W

Technical Specifications

Parameters and characteristics for this part

Specification	VX78012-1000

Applications	ITE (Commercial)
Approval Agency	EN, CB Scheme, UL, IEC
Current - Output (Max) [Max]	1 A
Efficiency	96 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	3-SIP Module
Power (Watts)	12 W
Size / Dimension [x]	0.45 in
Size / Dimension [x]	11.5 mm
Size / Dimension [y]	0.35 "
Size / Dimension [y]	9 mm
Size / Dimension [z]	0.69 "
Size / Dimension [z]	17.5 mm
Standard Number	55024, 60950-1, 55032 Class A
Type	Linear Regulator Replacement
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	16 V
Voltage - Output 1	12 V

Part	Power (Watts)	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Standard Number	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Number of Outputs	Mounting Type	Voltage - Input (Min) [Min]	Efficiency	Voltage - Input (Max) [Max]	Approval Agency	Type	Current - Output (Max) [Max]
CUI Inc. VX78012-1000	12 W	12 V	85 °C	-40 °C	3-SIP Module	55024 55032 Class A 60950-1	ITE (Commercial)	0.69 "	0.45 in	0.35 "	11.5 mm	9 mm	17.5 mm	1	Through Hole	16 V	96 %	36 V	CB Scheme EN IEC UL	Linear Regulator Replacement	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Linear Regulator Replacement DC DC Converter 1 Output 12V 1A 16V - 36V Input

Technical documentation and resources

No documents available
