CPA500-4530G
ActiveEOS Power India Private Ltd
AC/DC CNVRTR 5V 3.3V +/-12V 500W
Deep-Dive with AI
Search across all available documentation for this part.
CPA500-4530G
ActiveEOS Power India Private Ltd
AC/DC CNVRTR 5V 3.3V +/-12V 500W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CPA500-4530G |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cCSAus, CE, TUV, cULus |
| Current - Output 1 | 50 A |
| Current - Output 2 | 60 A |
| Current - Output 3 | 12 A |
| Current - Output 4 | 4 A |
| Efficiency | 84 % |
| Features | DC Input Capable, Remote Sense, Load Sharing, Hot Swappable, PFC |
| Minimum Load Required | False |
| Mounting Type | Compact PCI® |
| Number of Outputs | 4 |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -25 °C |
| Power (Watts) | 500 W |
| Size / Dimension [x] | 6.67 in, 169.5 mm |
| Size / Dimension [y] | 1.59 in, 40.3 mm |
| Size / Dimension [z] | 10.31 in, 261.9 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | 3.3 V |
| Voltage - Output 3 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 833.25 | |
| 5 | $ 805.48 | |||
| 10 | $ 777.70 | |||
Description
General part information
CPA500 Series
Enclosed AC DC Converters 4 Output 5V 3.3V 12V -12V 90 ~ 264 VAC Input
