M38908 SL005
ActiveALPHA WIRE
CABLE 8COND 24AWG SLATE
Deep-Dive with AI
Search across all available documentation for this part.
M38908 SL005
ActiveALPHA WIRE
CABLE 8COND 24AWG SLATE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M38908 SL005 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 32 AWG |
| Conductor Strand [custom] | 7 |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Slate |
| Length [x] | 30.5 m |
| Length [x] | 100 ft |
| Number of Conductors | 8 |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -20 C |
| Ratings | UL Style 2464 |
| Voltage | 300 V |
| Wire Gauge | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 100 | $ 1.89 | |
| 200 | $ 1.80 | |||
| 300 | $ 1.75 | |||
| 500 | $ 1.68 | |||
| 700 | $ 1.64 | |||
| 1000 | $ 1.60 | |||
| 2500 | $ 1.50 | |||
Description
General part information
M38908 Series
8 Conductor Multi-Conductor Cable Slate 24 AWG 100.0' (30.5m)
Documents
Technical documentation and resources
