DD11.0124.1110

Active

SCHURTER Inc.

PWR ENT MOD RCPT IEC320-C14 PNL

Search across all available documentation for this part.

Active

SCHURTER Inc.

PWR ENT MOD RCPT IEC320-C14 PNL

Technical Specifications

Parameters and characteristics for this part

Specification	DD11.0124.1110

Accomodates a Fuse	True
Approval Agency	ENEC, cULus
Connector Style	IEC 320-C14
Connector Type	Receptacle, Male Blades - Module
Current Rating - Appliance Inlet	10 A
Filter Type	Unfiltered - Commercial
Fuse Holder, Drawer	Drawer Sold Separate
Ingress Protection	IP40
Material Flammability Rating	UL94 V-0
Mounting Type	Panel Mount, Flange
Switch Features	Illuminated, Switch On-Off
Termination	0.189 ", 4.8 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet	250 VAC

Part	Mounting Type	Fuse Holder, Drawer	Accomodates a Fuse	Switch Features	Ingress Protection	Filter Type	Approval Agency	Material Flammability Rating	Current Rating - Appliance Inlet	Termination	Termination	Connector Style	Voltage Rating - Appliance Inlet	Connector Type
SCHURTER Inc. DD11.0124.1110	Flange Panel Mount	Drawer Sold Separate		Illuminated Switch On-Off	IP40	Unfiltered - Commercial	cULus ENEC	UL94 V-0	10 A	0.189 " 4.8 mm	Quick Connect	IEC 320-C14	250 VAC	Receptacle Male Blades - Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Power Entry Connector Receptacle, Male Blades - Module IEC 320-C14 Panel Mount, Flange

Technical documentation and resources
