TRR09B395KGS - MFG_CERCAPRADKEMET.jpg

TRR09B395KGS

Active
KEMET

CAP CER 3.9UF 50V X7R RADIAL

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsKEM_C1117_T-SERIES.pdfTRR09B395KGS+1
TRR09B395KGS - MFG_CERCAPRADKEMET.jpg

TRR09B395KGS

Active
KEMET

CAP CER 3.9UF 50V X7R RADIAL

Deep-Dive with AI

DocumentsKEM_C1117_T-SERIES.pdfTRR09B395KGS+1

Technical Specifications

Parameters and characteristics for this part

SpecificationTRR09B395KGS
ApplicationsGeneral Purpose
Capacitance3.9 µF
FeaturesHigh Temperature
Height - Seated (Max) [Max] [z]12.7 mm
Height - Seated (Max) [Max] [z]0.5 in
Lead Spacing10.16 mm
Lead Spacing0.4 in
Lead StyleStraight
Mounting TypeThrough Hole
Operating Temperature [Max]260 ░C
Operating Temperature [Min]-55 °C
Package / CaseRadial
Size / Dimension [x]0.5 in
Size / Dimension [x]12.7 mm
Size / Dimension [y]3.81 mm
Size / Dimension [y]0.15 "
Temperature CoefficientX7R
Tolerance10 %
Voltage - Rated50 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$

Description

General part information

TRR09B Series

3.9 µF ±10% 50V Ceramic Capacitor X7R Radial
