TXM-418-LC

Active

TE Connectivity Linx

RF TX IC ASK/OOK 418MHZ 8SMD MOD

Search across all available documentation for this part.

Active

TE Connectivity Linx

RF TX IC ASK/OOK 418MHZ 8SMD MOD

Technical Specifications

Parameters and characteristics for this part

Specification	TXM-418-LC

Antenna Connector	Castellation
Applications	Remote Control, Lighting, Home/Industrial Automation, Security, RKE
Current - Transmitting	5.2 mA
Data Interface	Serial
Data Rate (Max)	5 kbps
Frequency	418 MHz
Modulation or Protocol	ASK, OOK
Mounting Type	Surface Mount
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-30 ░C
Package / Case	8-SMD Module
Power - Output [Max]	4 dBm
Power - Output [Min]	-4 dBm
Supplier Device Package	Module
Voltage - Supply [Max]	5.2 V
Voltage - Supply [Min]	2.7 V

Part	Supplier Device Package	Antenna Connector	Frequency	Modulation or Protocol	Voltage - Supply [Min]	Voltage - Supply [Max]	Current - Transmitting	Mounting Type	Data Interface	Power - Output [Max]	Power - Output [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Package / Case	Data Rate (Max) [Max]	Data Rate (Max)
TE Connectivity Linx TXM-418-LR	Module	Castellation	418 MHz	ASK OOK	2.1 V	3.6 V	8.5 mA	Surface Mount	Serial	4 dBm	-4 dBm	85 °C	-40 °C	Home/Industrial Automation Lighting Remote Control RKE Security	8-SMD Module	10 kbps
TE Connectivity Linx TXM-418-LC	Module	Castellation	418 MHz	ASK OOK	2.7 V	5.2 V	5.2 mA	Surface Mount	Serial	4 dBm	-4 dBm	70 °C	-30 ░C	Home/Industrial Automation Lighting Remote Control RKE Security	8-SMD Module		5 kbps

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF Transmitter ASK, OOK 418MHz -4dBm ~ 4dBm 5kbps Castellation Antenna 8-SMD Module
