DC0011/10-TI900-0.12-0

Active

t-Global Technology

THERM PAD 19.05MMX12.7MM WHT

Search across all available documentation for this part.

Active

t-Global Technology

THERM PAD 19.05MMX12.7MM WHT

Technical Specifications

Parameters and characteristics for this part

Part	Adhesive	Shape	Usage	Shelf Life Start	Shelf Life	Thermal Conductivity	Color	Type	Thickness [custom]	Thickness [custom]	Outline [x]	Outline [y]	Material	Thickness	Thickness	Backing, Carrier	Thickness [x]	Thickness [x]
t-Global Technology DC0011/10-TG-A486G-0.3-2A	Adhesive - Both Sides	Rectangular	TO-220	Date of Purchase	12 Months	6 W/m-K	Gray	Die-Cut Pad Sheet	0.305 mm	0.012 "	19.05 mm	12.7 mm
t-Global Technology DC0011/10-TG-A482K-0.1-0		Rectangular	TO-220	Date of Purchase	24 Months	2.3 W/m-K	Red	Die-Cut Pad Sheet			19.05 mm	12.7 mm	Silicone	0.1 mm	0.0039 in
t-Global Technology DC0011/10-TI900-0.12-2A	Adhesive - Both Sides	Rectangular	TO-220		24 Months	1.8 W/m-K	White	Die-Cut Pad Sheet			19.05 mm	12.7 mm	Silicone			Viscose	0.005 in	0.127 mm
t-Global Technology DC0011/10-TI900-0.12-0		Rectangular	TO-220		24 Months	1.8 W/m-K	White	Die-Cut Pad Sheet			19.05 mm	12.7 mm	Silicone			Viscose	0.005 in	0.127 mm
t-Global Technology DC0011/10-TG-A373F-0.25-2A	Adhesive - Both Sides	Rectangular	TO-220		12 Months	1.4 W/m-K	Yellow	Die-Cut Pad Sheet	0.254 mm	0.01 in	19.05 mm	12.7 mm
