RDH60072WS12

Active

XP POWER

DC DC CONVERTER 12V 600W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER 12V 600W

Technical Specifications

Parameters and characteristics for this part

Specification	RDH60072WS12

Applications	Railway
Current - Output (Max) [Max]	50 A
Efficiency	87 %
Features	OCP, UVLO, OTP, Remote On/Off, SCP, OVP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Package / Case	Full Brick
Power (Watts)	600 W
Size / Dimension [x]	4.6 "
Size / Dimension [x]	116.8 mm
Size / Dimension [y]	2.4 "
Size / Dimension [y]	61 mm
Size / Dimension [z]	0.5 in
Size / Dimension [z]	12.7 mm
Supplier Device Package	Full Brick
Type	Isolated Module
Voltage - Input (Max) [Max]	160 V
Voltage - Input (Min) [Min]	43 V
Voltage - Isolation	3000 V
Voltage - Output 1	12 V

Part	Applications	Efficiency	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output (Max) [Max]	Features	Supplier Device Package	Voltage - Input (Max) [Max]	Mounting Type	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Isolation	Package / Case	Type
XP POWER RDH60072WS28	Railway	88 %	28 V	0.5 in	4.6 "	116.8 mm	12.7 mm	2.4 "	61 mm	1	100 °C	-40 °C	21.4 A	OCP OTP OVP Remote On/Off SCP UVLO	Full Brick	160 V	Through Hole	43 V	600 W	3000 V	Full Brick	Isolated Module
XP POWER RDH60072WS12	Railway	87 %	12 V	0.5 in	4.6 "	116.8 mm	12.7 mm	2.4 "	61 mm	1	100 °C	-40 °C	50 A	OCP OTP OVP Remote On/Off SCP UVLO	Full Brick	160 V	Through Hole	43 V	600 W	3000 V	Full Brick	Isolated Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 12V 50A 43V - 160V Input
