LK1301-9ERG
ActiveEOS Power India Private Ltd
AC/DC CONVERTER 12V 144W
Deep-Dive with AI
Search across all available documentation for this part.
LK1301-9ERG
ActiveEOS Power India Private Ltd
AC/DC CONVERTER 12V 144W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | LK1301-9ERG |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | cCSAus, CE, NEMKO |
| Current - Output 1 | 12 A |
| Efficiency | 83 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 144 W |
| Size / Dimension [x] | 168 mm |
| Size / Dimension [x] | 6.6 " |
| Size / Dimension [y] | 111 mm |
| Size / Dimension [y] | 4.4 " |
| Size / Dimension [z] | 3.2 in |
| Size / Dimension [z] | 80 mm |
| Type | Conformal Coated, Enclosed |
| Voltage - Input [Max] | 240 VAC, 372 VDC |
| Voltage - Input [Min] | 88 VDC, 100 VAC |
| Voltage - Isolation | 2000 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1173.08 | |
| 5 | $ 1105.14 | |||
Description
General part information
LK1301 Series
Enclosed, Conformal Coated AC DC Converters 1 Output 12V 100 ~ 240 VAC, 88 ~ 372 VDC Input
