AEDC-5550-W12

Active

Broadcom Limited

ROTARY ENCODER OPTICAL 5000PPR

Search across all available documentation for this part.

Active

Broadcom Limited

ROTARY ENCODER OPTICAL 5000PPR

Technical Specifications

Parameters and characteristics for this part

Specification	AEDC-5550-W12

Actuator Type	Hole for Shaft
Built in Switch	False
Detent	False
Encoder Type	Optical
Output Type	Quadrature with Index (Incremental)
Pulses per Revolution	5000
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V

Part	Actuator Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Encoder Type	Termination Style	Pulses per Revolution	Orientation	Mounting Type	Output Type
Broadcom Limited AEDC-5550-T12	Hole for Shaft	4.5 V	5.5 V	Optical	Terminal Pins	2000 pulses per revolution	Right Angle	Chassis Mount
Broadcom Limited AEDC-5550-J13	Hole for Shaft	4.5 V	5.5 V	Optical	Terminal Pins	1024	Right Angle	Chassis Mount
Broadcom Limited AEDC-5550-W12	Hole for Shaft	4.5 V	5.5 V	Optical		5000			Quadrature with Index (Incremental)
Broadcom Limited AEDC-5550-B12	Hole for Shaft	4.5 V	5.5 V	Optical	Terminal Pins	1000	Right Angle	Chassis Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Rotary Encoder Optical 5000 Quadrature with Index (Incremental)
