9GP5724P5H001

Active

Sanyo Denki America Inc.

FAN AXIAL 172X51MM 24VDC WIRE

Search across all available documentation for this part.

Active

Sanyo Denki America Inc.

FAN AXIAL 172X51MM 24VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	9GP5724P5H001

Air Flow	12.15 m³/min
Air Flow	434 CFM
Approval Agency	cURus, TUV
Bearing Type	Ball
Current Rating (Amps)	5 A
Fan Type	Tubeaxial
Features	Speed Sensor (Tach), PWM Control
Lifetime @ Temp.	Varies Based on Temperature
Material - Blade	Plastic
Material - Frame	Aluminum
Noise	77 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 °C
Operating Temperature [Min]	-20 C
Power (Watts)	120 W
RPM	8000 RPM
Size / Dimension	Rectangular/Rounded
Size / Dimension [x]	172 mm
Size / Dimension [z]	150 mm
Static Pressure	1000.6 Pa
Static Pressure	4.017 in H2O
Termination	4 Wire Leads
Voltage - Rated	24 VDC
Voltage Range [Max]	30 V
Voltage Range [Min]	16 VDC
Weight	861.8 g
Weight	1.9 lbs
Width [y]	51 mm

Part	Size / Dimension	Size / Dimension [z]	Size / Dimension [x]	Power (Watts)	Voltage Range [Min]	Voltage Range [Max]	Approval Agency	Bearing Type	Material - Frame	Features	Voltage - Rated	Air Flow	Air Flow	Termination	Static Pressure	Static Pressure	Current Rating (Amps)	Fan Type	Width [y]	RPM	Noise	Weight	Weight	Material - Blade	Lifetime @ Temp.	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Max]
Sanyo Denki America Inc. 9GP5724P5H001	Rectangular/Rounded	150 mm	172 mm	120 W	16 VDC	30 V	cURus TUV	Ball	Aluminum	PWM Control Speed Sensor (Tach)	24 VDC	12.15 m³/min	434 CFM	4 Wire Leads	1000.6 Pa	4.017 in H2O	5 A	Tubeaxial	51 mm	8000 RPM	77 dB	861.8 g	1.9 lbs	Plastic	Varies Based on Temperature	-20 °C	70 °C	-20 C	70 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Tubeaxial 24VDC Rectangular/Rounded - 172mm L x 150mm H Ball 434.0 CFM (12.15m³/min) 4 Wire Leads
