2N4923

Obsolete

STMicroelectronics

TRANS NPN 80V 1A SOT-32

Search across all available documentation for this part.

Obsolete

STMicroelectronics

TRANS NPN 80V 1A SOT-32

Technical Specifications

Parameters and characteristics for this part

Specification	2N4923

Current - Collector (Ic) (Max) [Max]	1 A
Current - Collector Cutoff (Max) [Max]	500 çA
DC Current Gain (hFE) (Min) @ Ic, Vce	30 hFE
Frequency - Transition	3 MHz
Mounting Type	Through Hole
Operating Temperature	150 °C
Package / Case	TO-225AA, TO-126-3
Power - Max [Max]	30 W
Transistor Type	NPN
Vce Saturation (Max) @ Ib, Ic	600 mV
Voltage - Collector Emitter Breakdown (Max) [Max]	80 V

Part	Frequency - Transition	Power - Max [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce	Operating Temperature	Current - Collector Cutoff (Max) [Max]	Voltage - Collector Emitter Breakdown (Max) [Max]	Vce Saturation (Max) @ Ib, Ic	Package / Case	Mounting Type	Transistor Type	Current - Collector (Ic) (Max) [Max]
STMicroelectronics 2N4923	3 MHz	30 W	30 hFE	150 °C	500 çA	80 V	600 mV	TO-126-3 TO-225AA	Through Hole	NPN	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Bipolar (BJT) Transistor NPN 80 V 1 A 3MHz 30 W Through Hole

Technical documentation and resources

No documents available
