WD-30-TRI

Obsolete

OK INDUSTRIES

WIRE WW 30AWG PVDF MULTIPLE 50'

Search across all available documentation for this part.

Obsolete

OK INDUSTRIES

WIRE WW 30AWG PVDF MULTIPLE 50'

Technical Specifications

Parameters and characteristics for this part

Specification	WD-30-TRI

Conductor Diameter [diameter]	0.25 mm
Conductor Diameter [diameter]	0.01 in
Conductor Material	Copper, Bare
Conductor Plating	Silver
Features	With Dispenser
Jacket (Insulation) Diameter [diameter]	0.019 in
Jacket (Insulation) Diameter [diameter]	0.5 mm
Jacket (Insulation) Material	Polyvinylidene Fluoride (PVDF)
Jacket Color	Multiple
Length [x]	50 ft
Length [x]	15.24 m
Ratings	VW-1, UL Style 1423
Wire Gauge	30 AWG

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Features	Jacket Color	Conductor Diameter [diameter]	Conductor Diameter [diameter]	Conductor Material	Conductor Plating	Ratings	Length [x]	Length [x]	Wire Gauge
OK INDUSTRIES WD-30-B	0.019 in	0.5 mm	Polyvinylidene Fluoride (PVDF)	With Dispenser	Blue	0.25 mm	0.01 in	Copper Bare	Silver	UL Style 1423 VW-1	50 ft	15.24 m	30 AWG
OK INDUSTRIES WD-30-Y	0.019 in	0.5 mm	Polyvinylidene Fluoride (PVDF)	With Dispenser	Yellow	0.25 mm	0.01 in	Copper Bare	Silver	UL Style 1423 VW-1	50 ft	15.24 m	30 AWG
OK INDUSTRIES WD-30-TRI	0.019 in	0.5 mm	Polyvinylidene Fluoride (PVDF)	With Dispenser	Multiple	0.25 mm	0.01 in	Copper Bare	Silver	UL Style 1423 VW-1	50 ft	15.24 m	30 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Wire Wrap 30 AWG Multiple Polyvinylidene Fluoride (PVDF) 50' (15.24m) With Dispenser
