D1U2-W-400-12-HA4C

Active

Murata Power Solutions Inc.

AC/DC CONVERTER 12V 400W

Search across all available documentation for this part.

Active

Murata Power Solutions Inc.

AC/DC CONVERTER 12V 400W

Technical Specifications

Parameters and characteristics for this part

Specification	D1U2-W-400-12-HA4C

Applications	ITE (Commercial)
Approval Agency	CB, TUV, CE, cCSAus
Current - Output 1	33.3 A
Efficiency	85 %
Features	I2C Interface, Hot Swappable, Load Sharing, Standby Output, Remote Sense, PFC, Universal Input
Mounting Type	Rack Mount
Number of Outputs	1
Size / Dimension [x]	347.2 mm
Size / Dimension [x]	13.67 in
Size / Dimension [y]	54.5 mm
Size / Dimension [y]	2.15 "
Size / Dimension [z]	1.58 "
Size / Dimension [z]	40.2 mm
Type	Front End
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Isolation	3000 V
Voltage - Output 1	12 V

Part	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Approval Agency	Features	Mounting Type	Voltage - Output 1	Type	Applications	Number of Outputs	Efficiency	Current - Output 1
Murata Power Solutions Inc. D1U2-W-400-12-HA4C	90 VAC	264 VAC	3000 V	54.5 mm	2.15 "	1.58 "	347.2 mm	40.2 mm	13.67 in	CB cCSAus CE TUV	Hot Swappable I2C Interface Load Sharing PFC Remote Sense Standby Output Universal Input	Rack Mount	12 V	Front End	ITE (Commercial)	1	85 %	33.3 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	50	$ 324.12

General part information

Front End AC DC Converters 1 Output 12V 90 ~ 264 VAC Input

Technical documentation and resources
