AM1301-9RG
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 12V 48W
Deep-Dive with AI
Search across all available documentation for this part.
AM1301-9RG
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 12V 48W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1301-9RG |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | CE, cCSAus |
| Current - Output (Max) [Max] | 4 A |
| Efficiency | 79 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 48 W |
| Size / Dimension [x] | 168.5 mm |
| Size / Dimension [x] | 6.63 " |
| Size / Dimension [y] | 4.38 in |
| Size / Dimension [y] | 111.2 mm |
| Size / Dimension [z] | 38.7 mm |
| Size / Dimension [z] | 1.52 in |
| Type | Conformal Coated, Enclosed |
| Voltage - Input (Max) [Max] [custom] | 35 V |
| Voltage - Input (Min) [Min] | 8 V |
| Voltage - Isolation | 2.8 kV |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 742.35 | |
| 5 | $ 717.60 | |||
| 10 | $ 705.23 | |||
Description
General part information
AM1301 Series
Enclosed, Conformal Coated DC DC Converter 1 Output 12V 4A 35V Input
Documents
Technical documentation and resources
No documents available
