ACB-05PMFS-LC7001

Active

Amphenol LTW

MIDDLE STAMPING PIN

Search across all available documentation for this part.

Active

Amphenol LTW

MIDDLE STAMPING PIN

Technical Specifications

Parameters and characteristics for this part

Specification	ACB-05PMFS-LC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	C
Shielding	Unshielded
Voltage Rating	250 VDC

Part	Primary Material	Current Rating (Amps)	Voltage Rating	Connector Type	Orientation	Contact Material	Shell Finish	Operating Temperature [Min]	Operating Temperature [Max]	Color	Insert Material	Contact Finish - Mating	Mounting Feature	Shell Size - Insert	Shielding	Ingress Protection	Material Flammability Rating	Fastening Type	Shell Material
Amphenol LTW ACB-05PMFS-SC7001	Plastic	10 A	300 VDC	Receptacle Female Sockets	Keyed	Copper Alloy	Nickel	-40 °C	105 ░C	Black	Polyamide (PA) Nylon Glass Filled	Gold	Bulkhead - Front Side Nut	C	Unshielded	IP67 - Dust Tight Waterproof	UL94 V-0
Amphenol LTW ACB-05PMFS-LC7001	Plastic	10 A	250 VDC	Receptacle Female Sockets	Keyed	Copper Alloy		-40 °C	105 ░C	Black	Polyamide (PA) Nylon Glass Filled	Gold	Bulkhead - Front Side Nut	C	Unshielded	IP67 - Dust Tight Waterproof		Bayonet Lock	Glass Filled Nylon Polyamide (PA)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Position Circular Connector Receptacle, Female Sockets Solder Cup
