UMPT-08-01-L-RA-WT-TR
ActiveSamtec Inc.
CONN HDR 8POS 2.00MM R/A SLDR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UMPT-08-01-L-RA-WT-TR
ActiveSamtec Inc.
CONN HDR 8POS 2.00MM R/A SLDR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UMPT-08-01-L-RA-WT-TR |
|---|---|
| Color | Black |
| Connector Type | Male Blades, Header |
| Contact Finish | Gold |
| Contact Finish Thickness | 10 Áin |
| Contact Finish Thickness | 0.25 Ám |
| Contact Material | Copper Alloy |
| Features | Solder Retention |
| Material - Insulation | Liquid Crystal Polymer (LCP) |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Pitch [x] | 0.079 in |
| Pitch [x] | 2 mm |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 7.23 | |
| 10 | $ 6.68 | |||
| 25 | $ 6.32 | |||
| 50 | $ 6.09 | |||
| Digi-Reel® | 1 | $ 7.23 | ||
| 10 | $ 6.68 | |||
| 25 | $ 6.32 | |||
| 50 | $ 6.09 | |||
| Tape & Reel (TR) | 125 | $ 4.95 | ||
| 625 | $ 4.64 | |||
Description
General part information
UMPT-08 Series
8 Position Header, Male Blades Connector Solder 0.079" (2.00mm) Surface Mount, Right Angle
