AM1A-4805SZ
Activeaimtec
DC DC CONVERTER 5V 1W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AM1A-4805SZ
Activeaimtec
DC DC CONVERTER 5V 1W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1A-4805SZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus, UL |
| Current - Output (Max) [Max] | 200 mA |
| Efficiency | 76 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 6-SIP Module |
| Size / Dimension [x] | 17 mm |
| Size / Dimension [x] | 0.67 in |
| Size / Dimension [y] | 0.3 " |
| Size / Dimension [y] | 7.6 mm |
| Size / Dimension [z] | 11 mm |
| Size / Dimension [z] | 0.43 " |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 13.00 | |
| 5 | $ 12.61 | |||
| 10 | $ 12.22 | |||
| 25 | $ 11.70 | |||
| 40 | $ 11.58 | |||
| 80 | $ 11.35 | |||
| 160 | $ 10.92 | |||
| 320 | $ 10.70 | |||
Description
General part information
AM1A Series
Isolated Module DC DC Converter 1 Output 5V 200mA 36V - 75V Input
