RF55-23H-T-00-50-G-A-SH

Active

Adam Tech

FAKRA PLUG SMB TYPE: RIGHT ANGLE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet ECBT2-E224053 Data Connectors, Signal, Control, Power Applications

RF55-23H-T-00-50-G-A-SH

Active

Adam Tech

FAKRA PLUG SMB TYPE: RIGHT ANGLE

Deep-Dive with AI

DocumentsDatasheet ECBT2-E224053 Data Connectors, Signal, Control, Power Applications

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RF55-23H-T-00-50-G-A-SH

Body Finish	Gold
Body Material	Brass
Center Contact Material	Brass
Center Contact Plating	Gold
Connector Style	SMB, Fakra
Connector Type	Male Pin, Plug
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Locking Ramp
Features	Code H
Frequency - Max [Max]	4 GHz
Housing Color	Violet
Impedance	50 Ohms
Mounting Type	Through Hole, Right Angle
Number of Ports	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Shield Termination	Solder

RF55-23 Series

Part	Body Material	Number of Ports	Housing Color	Contact Termination	Features	Connector Style	Dielectric Material	Shield Termination	Impedance	Center Contact Material	Connector Type	Frequency - Max [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Center Contact Plating	Mounting Type	Body Finish	Fastening Type
Adam Tech RF55-23H-T-00-50-G-A-SH	Brass	1	Violet	Solder	Code H	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23N-T-00-50-G-A-SH	Brass	1	Green Pastel	Solder	Code N	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23I-T-00-50-G-A-SH	Brass	1	Beige	Solder	Code I	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23E-T-00-50-G-A-SH	Brass	1	Green	Solder	Code E	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23M-T-00-50-G-A-SH	Brass	1	Orange Pastel	Solder	Code M	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23D-T-00-50-G-A-SH	Brass	1	Bordeaux Violet	Solder	Code D	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23K-T-00-50-G-A-SH	Brass	1	Curry	Solder	Code K	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp
Adam Tech RF55-23C-T-00-50-G-A-SH	Brass	1	Blue	Solder	Code C	Fakra SMB	Polytetrafluoroethylene (PTFE)	Solder	50 Ohms	Brass	Male Pin Plug	4 GHz	85 °C	-40 °C	Gold	Through Hole Right Angle	Gold	Locking Ramp

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 3.27
		10	$ 2.50
		25	$ 2.25
		40	$ 2.14
