0191170083

Active

Molex

CONN SPADE TERM 14-16AWG #6

Search across all available documentation for this part.

Active

Molex

CONN SPADE TERM 14-16AWG #6

Technical Specifications

Parameters and characteristics for this part

Part	Termination	Contact Finish	Length - Overall [x]	Length - Overall [x]	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Mounting Type	Width - Outer Edges [x]	Width - Outer Edges [x]	Insulation	Wire Gauge [Max]	Wire Gauge [Min]	Terminal Type	Contact Material	Stud/Tab Size	Length - Ring Center to Termination [x]	Length - Ring Center to Termination	Length - Termination [custom]	Length - Termination [custom]	Length - Ring Center to Termination	Length - Termination	Length - Termination	Stud/Tab Size
Molex 0191170016	Crimp	Electro-Tin	0.635 in	16.13 mm	3.71 mm	0.146 in	Free Hanging (In-Line)	7.39 mm	0.291 in	Non-Insulated	22 AWG	17.5 AWG	Flanged	Copper	6 Stud	0.207 in	5.26 mm	0.245 in	6.22 mm
Molex 0191170084	Crimp	Electro-Tin	0.649 "	16.49 mm	4.39 mm	0.173 in	Free Hanging (In-Line)	7.65 mm	0.301 in	Non-Insulated			Flanged	Copper			5.31 mm			0.209 in	6.45 mm	0.254 in	8 Stud
Molex 0191170083	Crimp												Flanged		6 Stud

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6 Stud Spade Terminal Connector Crimp 14-16 AWG
