RDEC71H475K2P1H03B

Active

Murata Power Solutions Inc.

CAP CER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

RDEC71H475K2P1H03B

Active

Murata Power Solutions Inc.

CAP CER

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RDEC71H475K2P1H03B

Applications	General Purpose
Capacitance	4.7 µF
Height - Seated (Max) [Max]	0.236 in
Height - Seated (Max) [Max]	6 mm
Lead Spacing	5 mm
Lead Spacing	0.197 in
Lead Style	Formed Leads
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	Radial
Size / Dimension [diameter]	0.217 "
Size / Dimension [diameter]	5.5 mm
Size / Dimension [x]	3.15 mm
Size / Dimension [x]	0.124 in
Temperature Coefficient	X7S
Tolerance	10 %
Voltage - Rated	50 VDC

RDEC71H Series

Part	Lead Spacing	Lead Spacing	Temperature Coefficient	Mounting Type	Applications	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Package / Case	Lead Style	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Capacitance	Size / Dimension [y]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Size / Dimension [diameter]	Size / Dimension [diameter]
Murata Power Solutions Inc. RDEC71H475K2M1H03A	5 mm	0.197 in	X7S	Through Hole	General Purpose	10 %	0.236 in	6 mm	3.15 mm	0.124 "	5.5 mm	0.217 "	Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	4.7 µF
Murata Power Solutions Inc. RDEC71H106K3P1C03B	2.5 mm	0.098 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H106K3P1H03B	2.5 mm	0.098 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H106K3S1H03A	2.5 mm	0.098 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H106K3K1C03B	5 mm	0.197 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H106K3K1H03B	5 mm	0.197 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H106K3S1C03A	2.5 mm	0.098 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H475K2S1H03A
Murata Power Solutions Inc. RDEC71H106K3M1H03A	5 mm	0.197 in	X7S	Through Hole	General Purpose	10 %					0.217 in 5.5 mm		Radial	Formed Leads - Kinked	-55 °C	125 °C	50 VDC	10 µF	0.157 " 4 mm	0.295 in	7.5 mm
Murata Power Solutions Inc. RDEC71H475K2P1H03B	5 mm	0.197 in	X7S	Through Hole	General Purpose	10 %	0.236 in	6 mm			3.15 mm	0.124 in	Radial	Formed Leads	-55 °C	125 °C	50 VDC	4.7 µF				0.217 "	5.5 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.89
		10	$ 0.54
		50	$ 0.41
		100	$ 0.36
		500	$ 0.29
		1000	$ 0.27
		2500	$ 0.24
		5000	$ 0.23

Description

General part information

RDEC71H Series

4.7 µF ±10% 50V Ceramic Capacitor X7S Radial
