852-10-060-10-002101

Active

PRECI-DIP SA

CONN HEADER VERT 60POS 1.27MM

Deep-Dive with AI

Search across all available documentation for this part.

852-10-060-10-002101

Active

PRECI-DIP SA

CONN HEADER VERT 60POS 1.27MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	852-10-060-10-002101

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	10 çin
Contact Finish Thickness - Mating	0.25 çm
Contact Finish Thickness - Post	10 çin
Contact Finish Thickness - Post	0.25 çm
Contact Length - Mating	3 mm
Contact Length - Mating	0.118 in
Contact Length - Post	0.118 in
Contact Length - Post	3 mm
Contact Material	Brass
Contact Shape	Circular
Contact Type	Male Pin
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Material	Polyester, Glass Filled, Polycyclohexylenedimethylene Terephthalate (PCT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	60
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Overall Contact Length [x]	8.1 mm
Overall Contact Length [x]	0.319 in
Pitch - Mating	0.05 in
Pitch - Mating	1.27 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Shrouding	Unshrouded
Termination	Solder
Voltage Rating	150 VDC

852-10 Series

...

Part	Termination	Contact Material	Fastening Type	Contact Length - Mating	Contact Length - Mating	Number of Rows	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating	Pitch - Mating	Mounting Type	Insulation Color	Features	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Connector Type	Material Flammability Rating	Contact Finish - Post	Voltage Rating	Shrouding	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Shape	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Contact Type	Number of Positions	Contact Length - Post	Contact Length - Post	Overall Contact Length [x]	Overall Contact Length [x]	Row Spacing - Mating	Row Spacing - Mating	Contact Length - Post [x]	Insulation Height	Insulation Height
PRECI-DIP SA 852-10-032-30-002191	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Surface Mount	Black	Pick and Place	10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded	2.54 mm	0.1 in	Circular	Gold	10 çin	0.25 çm	All	Male Pin
PRECI-DIP SA 852-10-024-30-051101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Surface Mount	Black	Board Guide	10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded	2.54 mm	0.1 in	Circular	Gold	10 çin	0.25 çm	All	Male Pin	24
PRECI-DIP SA 852-10-060-10-002101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Through Hole	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded	2.54 mm	0.1 in	Circular	Gold	10 çin	0.25 çm	All	Male Pin	60	0.118 in	3 mm	8.1 mm	0.319 in
PRECI-DIP SA 852-10-058-30-001101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Surface Mount	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded			Circular	Gold	10 çin	0.25 çm	All	Male Pin	58					0.05 in	1.27 mm
PRECI-DIP SA 852-10-006-20-001101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Through Hole Right Angle	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded			Circular	Gold	10 çin	0.25 çm	All	Male Pin	6		3.2 mm			0.05 in	1.27 mm	0.126 in	3.25 mm	0.128 in
PRECI-DIP SA 852-10-042-20-002101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Through Hole Right Angle	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded	2.54 mm	0.1 in	Circular	Gold	10 çin	0.25 çm	All	Male Pin	42		3.2 mm					0.126 in	4.42 mm	0.174 in
PRECI-DIP SA 852-10-068-30-001101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Surface Mount	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded			Circular	Gold	10 çin	0.25 çm	All	Male Pin	68					0.05 in	1.27 mm
PRECI-DIP SA 852-10-036-30-001191	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Surface Mount	Black	Pick and Place	10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded			Circular	Gold	10 çin	0.25 çm	All	Male Pin	36					0.05 in	1.27 mm
PRECI-DIP SA 852-10-024-20-002101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Through Hole Right Angle	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded	2.54 mm	0.1 in	Circular	Gold	10 çin	0.25 çm	All	Male Pin	24		3.2 mm					0.126 in	4.42 mm	0.174 in
PRECI-DIP SA 852-10-018-10-001101	Solder	Brass	Push-Pull	3 mm	0.118 in	2	-55 °C	125 °C	0.05 in	1.27 mm	Through Hole	Black		10 çin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Header	UL94 V-0	Gold	150 VDC	Unshrouded			Circular	Gold	10 çin	0.25 çm	All	Male Pin	18	0.118 in	3 mm	8.1 mm	0.319 in	0.05 in	1.27 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	70	$ 12.23

Description

General part information

852-10 Series

Connector Header Through Hole 60 position 0.050" (1.27mm)
