SSRK-240A30

Active

TE Connectivity Potter & Brumfield Relays

SSR RELAY SPST-NO 30A 24-240V

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

SSR RELAY SPST-NO 30A 24-240V

Technical Specifications

Parameters and characteristics for this part

Specification	SSRK-240A30

Load Current	30 A
Mounting Type	DIN Rail
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-30 ░C
Output Type	AC
Package / Case	SSR with Integrated Heat Sink
Termination Style	Screw Terminal
Voltage - Input [Max]	280 VAC/DC
Voltage - Input [Min]	90 VAC
Voltage - Load [Max]	240 V
Voltage - Load [Min]	24 V

Part	Voltage - Input [Max]	Voltage - Input [Min]	Package / Case	Output Type	Mounting Type	Voltage - Load [Min]	Voltage - Load [Max]	Termination Style	Operating Temperature [Min]	Operating Temperature [Max]	Load Current
TE Connectivity Potter & Brumfield Relays SSRK-240D20	32 V	3 V	SSR with Integrated Heat Sink	AC	DIN Rail	24 V	240 V	Screw Terminal	-30 ░C	80 C	20 A
TE Connectivity Potter & Brumfield Relays SSRK-240A30	280 VAC/DC	90 VAC	SSR with Integrated Heat Sink	AC	DIN Rail	24 V	240 V	Screw Terminal	-30 ░C	80 C	30 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State SPST-NO (1 Form A) SSR with Integrated Heat Sink
