1EDS5663HXUMA1
Infineon Technologies
DGT ISO 5.7KV 1CH GT DVR DSO16
Deep-Dive with AI
Search across all available documentation for this part.
1EDS5663HXUMA1
Infineon Technologies
DGT ISO 5.7KV 1CH GT DVR DSO16
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1EDS5663HXUMA1 |
|---|---|
| Approval Agency | UL, CSA, VDE, CQC |
| Common Mode Transient Immunity (Min) [Min] | 150 kV/µs |
| Current - Output High, Low | 4 A, 8 A |
| Mounting Type | Surface Mount |
| Number of Channels | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 16-SOIC |
| Package / Case [x] | 0.295 in |
| Package / Case [y] | 7.5 mm |
| Propagation Delay tpLH / tpHL (Max) [Max] | 44 ns |
| Pulse Width Distortion (Max) [Max] | 18 ns |
| Rise / Fall Time (Typ) [custom] | 4.5 ns |
| Rise / Fall Time (Typ) [custom] | 6.5 ns |
| Technology | Magnetic Coupling |
| Voltage - Isolation | 5700 Vrms |
| Voltage - Output Supply [Max] | 3.47 V |
| Voltage - Output Supply [Min] | 3.13 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.14 | |
| 10 | $ 2.82 | |||
| 25 | $ 2.66 | |||
| 100 | $ 2.31 | |||
| 250 | $ 2.19 | |||
| 500 | $ 1.96 | |||
| Digi-Reel® | 1 | $ 3.14 | ||
| 10 | $ 2.82 | |||
| 25 | $ 2.66 | |||
| 100 | $ 2.31 | |||
| 250 | $ 2.19 | |||
| 500 | $ 1.96 | |||
| Tape & Reel (TR) | 1000 | $ 1.66 | ||
| 2000 | $ 1.57 | |||
| 5000 | $ 1.51 | |||
Description
General part information
1EDS5663 Series
Gate Driver Magnetic Coupling 5700Vrms 1 Channel PG-DSO-16-30
