DKA30A-12

Active

MEAN WELL USA Inc.

DC DC CONVERTER +/-12V 30W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

DKA30A-12

Active

MEAN WELL USA Inc.

DC DC CONVERTER +/-12V 30W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	DKA30A-12

Applications	ITE (Commercial)
Current - Output (Max)	1.25 A
Efficiency	80 %
Features	Remote On/Off, OCP, SCP
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	8-DIP Module
Power (Watts)	30 W
Size / Dimension [x]	50.8 mm
Size / Dimension [x]	2 in
Size / Dimension [y]	2 in
Size / Dimension [y]	50.8 mm
Size / Dimension [z]	21 mm
Size / Dimension [z]	0.83 in
Type	Isolated Module
Voltage - Input (Max) [Max]	18 V
Voltage - Input (Min) [Min]	9 V
Voltage - Isolation	1000 V
Voltage - Output 1	12 V
Voltage - Output 2	-12 V

DKA30 Series

Part	Current - Output (Max)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Voltage - Output 1	Voltage - Input (Min) [Min]	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Voltage - Input (Max) [Max]	Power (Watts)	Type	Package / Case	Efficiency	Voltage - Isolation	Mounting Type	Features	Voltage - Output 2	Current - Output (Max)	Current - Output (Max) [Max]	Current - Output (Max) [Max]
MEAN WELL USA Inc. DKA30B-12	1.25 A	50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	12 V	18 V	2	85 °C	-40 °C	ITE (Commercial)	36 V	30 W	Isolated Module	8-DIP Module	83 %	1000 V	Through Hole	OCP Remote On/Off SCP	-12 V
MEAN WELL USA Inc. DKA30A-15	1 A	50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	15 V	9 V	2	85 °C	-40 °C	ITE (Commercial)	18 V	30 W	Isolated Module	8-DIP Module	80 %	1000 V	Through Hole	OCP Remote On/Off SCP	-15 V	1 A
MEAN WELL USA Inc. DKA30A-05		50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	5 V	9 V	2	85 °C	-40 °C	ITE (Commercial)	18 V	25 W	Isolated Module	8-DIP Module	80 %	1000 V	Through Hole	OCP Remote On/Off SCP	-5 V		2.5 A	2.5 A
MEAN WELL USA Inc. DKA30B-15	1 A	50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	15 V	18 V	2	85 °C	-40 °C	ITE (Commercial)	36 V	30 W	Isolated Module	8-DIP Module	83 %	1000 V	Through Hole	OCP Remote On/Off SCP	-15 V	1 A
MEAN WELL USA Inc. DKA30B-05		50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	5 V	18 V	2	85 °C	-40 °C	ITE (Commercial)	36 V	25 W	Isolated Module	8-DIP Module	80 %	1000 V	Through Hole	OCP Remote On/Off SCP	-5 V		2.5 A	2.5 A
MEAN WELL USA Inc. DKA30A-12	1.25 A	50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	12 V	9 V	2	85 °C	-40 °C	ITE (Commercial)	18 V	30 W	Isolated Module	8-DIP Module	80 %	1000 V	Through Hole	OCP Remote On/Off SCP	-12 V
MEAN WELL USA Inc. DKA30C-12	1.25 A	50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	12 V	36 V	2	85 °C	-40 °C	ITE (Commercial)	72 V	30 W	Isolated Module	8-DIP Module	81 %	1000 V	Through Hole	OCP Remote On/Off SCP	-12 V
MEAN WELL USA Inc. DKA30C-05		50.8 mm	21 mm	2 in	50.8 mm	2 in	0.83 in	5 V	36 V	2	85 °C	-40 °C	ITE (Commercial)	72 V	25 W	Isolated Module	8-DIP Module	80 %	1000 V	Through Hole	OCP Remote On/Off SCP	-5 V		2.5 A	2.5 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 27.02
		5	$ 25.48
		10	$ 24.84

Description

General part information

DKA30 Series

Isolated Module DC DC Converter 2 Output 12V -12V 1.25A, 1.25A 9V - 18V Input
