GA040TH65-227SP

Active

GeneSiC Semiconductor

MOD THYRISTOR CUSTOM SOT227

Search across all available documentation for this part.

Active

GeneSiC Semiconductor

MOD THYRISTOR CUSTOM SOT227

Technical Specifications

Parameters and characteristics for this part

Specification	GA040TH65-227SP

Current - Gate Trigger (Igt) (Max) [Max]	30 mA
Current - Hold (Ih) (Max) [Max]	780 mA
Current - On State (It (AV)) (Max) [Max]	40 A
Current - On State (It (RMS)) (Max)	69 A
Mounting Type	Chassis Mount
Number of SCRs, Diodes	1 SCR
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	Module
Structure	Single
Voltage - Off State	6.5 kV

Part	Structure	Voltage - Off State	Package / Case	Current - On State (It (AV)) (Max) [Max]	Current - Gate Trigger (Igt) (Max) [Max]	Current - Hold (Ih) (Max) [Max]	Current - On State (It (RMS)) (Max)	Number of SCRs, Diodes	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
GeneSiC Semiconductor GA040TH65	Single	6.5 kV	SOT-227-2	40 A	30 mA	780 mA	69 A	1 SCR	-55 °C	150 °C	Chassis Mount
GeneSiC Semiconductor GA040TH65-227SP	Single	6.5 kV	Module	40 A	30 mA	780 mA	69 A	1 SCR	-55 °C	150 °C	Chassis Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 1500.00

General part information

SCR Module 6.5 kV 69 A Single Chassis Mount Module
