AP3785TEV1

Active

Diodes Inc

EVAL BOARD FOR AP3785T

Search across all available documentation for this part.

Active

Diodes Inc

EVAL BOARD FOR AP3785T

Technical Specifications

Parameters and characteristics for this part

Part	Output Isolation	Package / Case	Package / Case [y]	Package / Case [x]	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Frequency - Switching	Topology	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Internal Switch(s)	Power (Watts)	Supplier Device Package	Fault Protection	Utilized IC / Part	Outputs and Type	Current - Output	Voltage - Output	Power - Output	Main Purpose	Contents	Regulator Topology	Voltage - Input [Min]	Voltage - Input [Max]
Diodes Inc AP3785HMTR-G1	Isolated	8-SOIC	3.9 mm	0.154 in	30 V	5.9 V	80 kHz	Flyback	Surface Mount	150 °C	-40 °C		15 W	8-SO	Over Temperature Over Voltage Short Circuit
Diodes Inc AP3785TEV1																AP3785T	1 Isolated Output	3 A	5 V	15 W	AC/DC Primary Side	Board(s)	Flyback	90 VAC	265 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AP3785T - 1 Isolated Output AC/DC, Primary Side Evaluation Board
