CP2E-BVE02R

Active

MEAN WELL USA Inc.

22MM/WITHOUT LIGHT/PUSH-IN/2NC/I

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

22MM/WITHOUT LIGHT/PUSH-IN/2NC/I

Technical Specifications

Parameters and characteristics for this part

Specification	CP2E-BVE02R

Circuit	DPST-NC
Current Rating (Amps)	8 A, 2.5 A
Ingress Protection	IP66
Mounting Type	Panel Mount, Front
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Panel Cutout Dimensions [diameter]	22.3 mm
Reset Operation	Pull
Switch Function	On-Off
Termination Style	Spring Terminal
Voltage Rating - AC	120 V
Voltage Rating - DC	30 V

Part	Ingress Protection	Reset Operation	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Circuit	Voltage Rating - DC	Voltage Rating - AC	Panel Cutout Dimensions [diameter]	Mounting Type	Switch Function	Termination Style
MEAN WELL USA Inc. CP2E-BVE02R	IP66	Pull	70 °C	-25 °C	2.5 A 8 A	DPST-NC	30 V	120 V	22.3 mm	Panel Mount Front	On-Off	Spring Terminal

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 14.57

General part information

22MM/WITHOUT LIGHT/PUSH-IN/2NC/I
