NDXD2415EC

Obsolete

Murata Power Solutions Inc.

DC DC CONVERTER +/-15V 7W

Search across all available documentation for this part.

Obsolete

Murata Power Solutions Inc.

DC DC CONVERTER +/-15V 7W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Output 1	Voltage - Isolation	Package / Case	Current - Output (Max)	Current - Output (Max)	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Type	Efficiency	Voltage - Output 2	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Power (Watts)	Number of Outputs	Applications
Murata Power Solutions Inc. NDXD2405C	5 V	1000 V	6-DIP Module	750 mA	750 mA	85 °C	-40 °C	Through Hole	Isolated Module	75 %	-5 V	36 V	18 V	7 W	2	ITE (Commercial)
Murata Power Solutions Inc. NDXD2415C	15 V	1000 V	6-DIP Module	250 mA	250 mA	85 °C	-40 °C	Through Hole	Isolated Module		-15 V	36 V	18 V	7 W	2	ITE (Commercial)
Murata Power Solutions Inc. NDXD2415EC	15 V	1000 V	6-DIP Module	250 mA	250 mA	85 °C	-40 °C	Through Hole	Isolated Module		-15 V	36 V	18 V	7 W	2	ITE (Commercial)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 250mA, 250mA 18V - 36V Input

Technical documentation and resources
