CMEJ-4622-25-L082
ActiveCUI Devices
MIC COND ANLG OMNI -25DB 0.181"D
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CMEJ-4622-25-L082
ActiveCUI Devices
MIC COND ANLG OMNI -25DB 0.181"D
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CMEJ-4622-25-L082 |
|---|---|
| Current - Supply | 500 µA |
| Direction | Omnidirectional |
| Frequency Range [Max] | 10 kHz |
| Frequency Range [Min] | 100 Hz |
| Height (Max) | 2.4 mm |
| Height (Max) [Max] | 0.094 in |
| Output Type | Analog |
| Port Location | Top |
| Ratings | IP65 |
| S/N Ratio | 65 dB |
| Sensitivity | -25 dB |
| Shape | Circular |
| Size / Dimension [diameter] | 0.181 in |
| Size / Dimension [diameter] | 4.6 mm |
| Termination | Wire Leads |
| Type | Electret Condenser |
| Voltage - Rated | 3 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 1.82 | |
| 10 | $ 1.48 | |||
| 25 | $ 1.37 | |||
| 50 | $ 1.29 | |||
| 100 | $ 1.21 | |||
| 250 | $ 1.12 | |||
| 500 | $ 1.05 | |||
| 1000 | $ 0.99 | |||
| 5000 | $ 0.94 | |||
Description
General part information
CMEJ-4622 Series
100 Hz ~ 10 kHz Analog Microphone Electret Condenser Omnidirectional (-25dB ±3dB @ 94dB SPL) Wire Leads
