VGS-35C-24

CUI Inc.

AC/DC CONVERTER 24V 36W

Deep-Dive with AI

Search across all available documentation for this part.

VGS-35C-24

CUI Inc.

AC/DC CONVERTER 24V 36W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	VGS-35C-24

Applications	Household Appliances, ITE (Commercial)
Approval Agency	CE, cURus
Current - Output 1	1.5 A
Efficiency	88 %
Features	Adjustable Output, Universal Input
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-30 °C
Power (Watts)	36 W
Size / Dimension [x]	99 mm
Size / Dimension [x]	3.9 "
Size / Dimension [y]	82 mm
Size / Dimension [y]	3.23 "
Size / Dimension [z]	30 mm
Size / Dimension [z]	1.18 in
Standard Number	60335-1, 62368-1
Type	Enclosed
Voltage - Input [Max]	264 VAC, 373 VDC
Voltage - Input [Min]	85 VAC, 120 VDC
Voltage - Isolation	4000 V
Voltage - Output 1	24 V

VGS-35C Series

Part	Features	Efficiency	Current - Output 1	Standard Number	Applications	Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input [Min]	Voltage - Input [Max]	Mounting Type	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Voltage - Isolation	Approval Agency	Power (Watts)	Voltage - Output 1	Number of Outputs
CUI Inc. VGS-35C-5	Adjustable Output Universal Input	83 %	7 A	60335-1 62368-1	Household Appliances ITE (Commercial)	Enclosed	70 °C	-30 °C	85 VAC 120 VDC	264 VAC 373 VDC	Chassis Mount	82 mm	30 mm	99 mm	3.23 "	1.18 in	3.9 "	4000 V	CE cURus	35 W	5 V	1
CUI Inc. VGS-35C-5-A	Adjustable Output Universal Input	83 %	7 A	60335-1 62368-1	Household Appliances ITE (Commercial)	Enclosed	70 °C	-30 °C	85 VAC 120 VDC	264 VAC 373 VDC	Chassis Mount	82 mm	30 mm	99 mm	3.23 "	1.18 in	3.9 "	4000 V	CE cURus	35 W	5 V	1
CUI Inc. VGS-35C-12-B	Adjustable Output Universal Input	87 %	3 A	60335-1 62368-1	Household Appliances ITE (Commercial)	Conformal Coated Enclosed	70 °C	-30 °C	85 VAC 120 VDC	264 VAC 373 VDC	Chassis Mount	82 mm	30 mm	99 mm	3.23 "	1.18 in	3.9 "	4000 V	CE cURus	36 W	12 V	1
CUI Inc. VGS-35C-15-A	Adjustable Output Universal Input	89 %	2.4 A	60335-1 62368-1	Household Appliances ITE (Commercial)	Enclosed	70 °C	-30 °C	85 VAC 120 VDC	264 VAC 373 VDC	Chassis Mount	82 mm	30 mm	99 mm	3.23 "	1.18 in	3.9 "	4000 V	CE cURus	36 W	15 V	1
CUI Inc. VGS-35C-24	Adjustable Output Universal Input	88 %	1.5 A	60335-1 62368-1	Household Appliances ITE (Commercial)	Enclosed	70 °C	-30 °C	85 VAC 120 VDC	264 VAC 373 VDC	Chassis Mount	82 mm	30 mm	99 mm	3.23 "	1.18 in	3.9 "	4000 V	CE cURus	36 W	24 V	1

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 13.52
		5	$ 13.33
		10	$ 13.13
		25	$ 12.36
		52	$ 11.98

Description

General part information

VGS-35C Series

Enclosed AC DC Converters 1 Output 24V 85 ~ 264 VAC, 120 ~ 373 VDC Input

Documents

Technical documentation and resources

No documents available
