34_N-SMA-50-1/193_UE

Active

Huber+Suhner, Inc.

Search across all available documentation for this part.

Active

Huber+Suhner, Inc.

34_N-SMA-50-1/193_UE

Technical Specifications

Parameters and characteristics for this part

Specification	34_N-SMA-50-1/193_UE

Adapter Type	Jack to Jack
Body Material	Stainless Steel
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Center Gender	Female to Female
Conversion Type	Between Series
Convert From (Adapter End)	Female Socket, SMA Jack
Convert To (Adapter End)	Female Socket, N Jack
Dielectric Material	Perfluoroalkoxy (PFA), Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	18 GHz
Impedance	50 Ohms
Mating Cycles	500
Mounting Feature	Bulkhead
Operating Temperature [Max]	165 °C
Operating Temperature [Min]	-65 ░C
Style	Straight

Part	Convert To (Adapter End)	Center Contact Plating	Adapter Type	Center Contact Material	Frequency - Max [Max]	Style	Body Material	Dielectric Material	Impedance	Mating Cycles	Center Gender	Convert From (Adapter End)	Mounting Feature	Conversion Type	Operating Temperature [Min]	Operating Temperature [Max]
Huber+Suhner, Inc. 34_N-SMA-50-1/193_UE	Female Socket N Jack	Gold	Jack to Jack	Beryllium Copper	18 GHz	Straight	Stainless Steel	Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE)	50 Ohms	500	Female to Female	Female Socket SMA Jack	Bulkhead	Between Series	-65 ░C	165 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Coaxial Connector SMA Jack, Female Socket To N Jack, Female Socket 50 Ohms
