UM-QLP-1.5W-6(43)

Obsolete

Hirose Electric USA, Inc.

CONN UMC PLUG R/A 50OHM SOLDER

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

UM-QLP-1.5W-6(43)

Obsolete

Hirose Electric USA, Inc.

CONN UMC PLUG R/A 50OHM SOLDER

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	UM-QLP-1.5W-6(43)

Body Finish	Nickel
Body Material	Brass
Cable Group	1.5D-HQEW, 1.5QEW, 1.5D-2W
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	U.FL (UMCC)
Connector Type	Plug, Female Socket
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Snap-On
Frequency - Max [Max]	2 GHz
Housing Color	Silver
Impedance	50 Ohms
Includes	1 Heat Shrink, 2 pcs - 1 Connector
Mating Cycles	500
Mounting Type	Free Hanging (In-Line), Right Angle
Number of Ports	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-30 ░C
Shield Termination	Crimp

UM-QLP-1 Series

Part	Fastening Type	Connector Type	Mounting Type	Body Finish	Frequency - Max [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Number of Ports	Center Contact Plating	Mating Cycles	Contact Termination	Impedance	Shield Termination	Cable Group	Body Material	Connector Style	Housing Color	Dielectric Material	Center Contact Material	Includes
Hirose Electric USA, Inc. UM-QLP-1.5-6(42)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Nickel	3 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Crimp	1.5D-2V	Brass	U.FL (UMCC)	Silver	Polytetrafluoroethylene (PTFE)	Beryllium Copper
Hirose Electric USA, Inc. UM-QLP-196/U(41)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Gold	3 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Clamp	RG-196	Brass	U.FL (UMCC)	Gold	Polytetrafluoroethylene (PTFE)	Beryllium Copper
Hirose Electric USA, Inc. UM-QLP-1.5W-6(40)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Nickel	2 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Crimp	1.5D-2W 1.5D-HQEW 1.5QEW	Brass	U.FL (UMCC)	Silver	Polytetrafluoroethylene (PTFE)	Beryllium Copper	1 Heat Shrink 2 pcs - 1 Connector
Hirose Electric USA, Inc. UM-QLP-1.5-6(40)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Nickel	2 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Crimp	1.5D-2V 1.5D-HQEV 1.5D-QEV	Brass	U.FL (UMCC)	Silver	Polytetrafluoroethylene (PTFE)	Beryllium Copper	1 Heat Shrink 2 pcs - 1 Connector
Hirose Electric USA, Inc. UM-QLP-1.5DQS(40)
Hirose Electric USA, Inc. UM-QLP-1.5-6(48)
Hirose Electric USA, Inc. UM-QLP-1.5W-6(43)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Nickel	2 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Crimp	1.5D-2W 1.5D-HQEW 1.5QEW	Brass	U.FL (UMCC)	Silver	Polytetrafluoroethylene (PTFE)	Beryllium Copper	1 Heat Shrink 2 pcs - 1 Connector
Hirose Electric USA, Inc. UM-QLP-1.5W-9(40)
Hirose Electric USA, Inc. UM-QLP-1.5W-6(41)	Snap-On	Female Socket Plug	Free Hanging (In-Line) Right Angle	Nickel	3 GHz	-30 ░C	85 °C	1	Gold	500	Solder	50 Ohms	Crimp	1.5D-2W	Brass	U.FL (UMCC)	Silver	Polytetrafluoroethylene (PTFE)	Beryllium Copper

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

UM-QLP-1 Series

U.FL (UMCC) Connector Plug, Female Socket 50 Ohms Free Hanging (In-Line), Right Angle Solder
